How to operate automatic discharge gold concentrator?

automatic discharge centrifugal concentrator

automatic discharge centrifugal concentrator

automatic discharge centrifugal concentrator

automatic discharge centrifugal concentrator


Operation process

1)Open the PLC control box, turn on the main power, then getting into the system and setting parameters, waiting for the air compressor to inflate;

2)Start the centrifugal pump and adjust the water pressure to about 0.3MPa by switch. (the water pressure needs to sum up the experience and adjust itself according to the actual situation);

3)Click on the automatic mode of "Cycle" to start work;

4)Shut down: firstly should turn off the feeding of raw material, when discharge finished click "automatic stop", turn off the main power and finally turn off the centrifugal pump.

The maintainence

1)Because the knelson centrifuge gold concentrator is rotating at high speed, it will produce vibration, so we should check whether the bolt is loose or not at any time.If loose there will be abnormal sound, please stop in time to check.

2)Weather, temperature, humidity and other factors will have a greater impact on the life of V-belt, please check if need change please replace one whole set.

3)Butter must be added to each shift for 8 hours. Lack of oil can cause damage to bearings.

If problems cann’t be solved please contact Qingzhou Guancheng Heavy Industrial Machinery Co., Ltd. (It’s better to send photos,video to our company via email then we can response very soon)

Detail parameter


Production Name


Specification


Capacity


Power


Weight


Horizontal knelson centrifuge gold concentrator

2450*1720*1690

5-7

6.05

2400kgs


Horizontal knelson centrifuge gold concentrator

2450*1720*1690

15-30

6.05

2600kgs


Horizontal knelson centrifuge gold concentrator

2780*1850*1950

30-50

10.5

3200kgs


Horizontal knelson centrifuge gold concentrator

3800*1900*2950

100-120

21.5

7800kgs
