Knelson Gold Centrifugal Concentrator For Mineral Separator

Knelson Gold Centrifugal

Knelson Gold Centrifugal Concentrator

Product Description
Knelson Gold Centrifugal Concentrator For Mineral Separator
Knelson Type Centrifugal Gold Concentrator is a new type of gravity concentration equipment for gold separating and other high density minerals. The centrifugal machine has many competitive advantages compared with other concentration machines which create high returns for the investors.We have fully-continuous (Knelson Continuous Variable- Discharge, CVD type) and semi-continuous(Batch type) centrifugal gold concentrators.
The raw ore smaller than 4mm/6mm will be mixed to slurry and go into the centrifugal machine after sieving by trommel screen. The production capacity can be 50-200m³/hr according to the amount/size of centrifugal machine, fluctuation sluice and gold grass.


Technical Parameters

Model
(GC-STL)

Size
L*W*H

Capacity
T/h


Motor speed
R/min


Feeding size
mm


Water needed


Feeding concentration

Weight
kg

Pressure
MPa

Discharging time
(Min.)

Motor Power
Kw

GC-STL-40

1650*1500*1300

1-3

480

≤6

9-15

30%

617

0.1-0.5

1-2

GC-STL-60

2100*1900*1700

20-30

480

≤6

21-35

30%

1170

0.1-0.5

2-4

7.5

GC-STL-80

2750*2600*2150

30-50

420

≤6

36-50

30%

2040

0.1-0.5

4-8

11



Any question pls feel free to contact: Mr Li 0086 15053659999/0086 15653473333
Advantages for Gold centrifugal concentrator
1) High recovery rate: Through our test, the recovery rate for placer gold can be 98% or more, for rock gold, the recovery rate could reach 97% when the feeding size is below 7mm.

2) Easy to install: Only a small leveled place required. It's a full line machine, before starting it, we only need to connect the water pump and power.

3) Easy to adjust: There are only 2 factors that will affect the recovery result, they are water pressure and feeding size. By giving proper water pressure and feeding size, you could get the best recovery effect.

4) No pollution: This machine only consumes water and electric power, and exhaust tailing and water. Low noise, no chemical agent involved.

5) Easy to operate: After finishing the water pressure and feeding size adjust, clients only need to recover the concentrates every 2-4 hours. (Depending on the grade of the mine)

Qingzhou Guancheng Heavy Indurstrial Co.,Ltd is a famous&professional centrifuge concentrator in china,we have design and developed the technology in 10years.Now it contains Auto discharge horizontal centrifuge concentrator, Auto discharge vertical type,Handling discharge vertical type etc&totally more than 10 models for your chosen.Hope we can have business cooperation!
Below details of Auto discharge horizontal centrifuge concentrator for your information.
